Dewpoint transmitters are increasingly playing a more important role in many industrial applications, such as drying processes, air pressure pipelines, compressed air systems, and much more. A dew point sensor is directly installed in the pipe or by means of a sampling system. The latter is needed if the dew point temperature has to be measured at standard conditions: atmospheric pressure and ambient temperature. A dew point monitor is equipped with either a remote probe, (like the Superdew 3 and the Series EE35), or are designed for direct mounting.

Read More

Inline Dewpoint Transmitters

The Shaw Moisture Meters Model SDT are compact, two wire, 4–20 mA dewpoint transmitters designed to meet the stringent demands of industrial applications. The dew point transmitter unit is fully self-contained within a robust housing, providing weatherproof protection to IP66 / NEMA 4X. Utilizing the Ultra High Capacitance Shaw Moisture Sensor, various dewpoint ranges are available, covering an overall range from -100 to +20 °C (-148 to +68 °F) dew point temperature. The Model SDT is supplied ready to use, with a calibration certificate traceable to National and International humidity standards.

The inline dew point sensors Series EE354 are developed for monitoring dew point temperature down to -20 °C (-4 °F) dew point. The high measurement accuracy of ±1 °C (±1.8 °F) in the typical working range of a refrigeration dryer makes the EE354 the ideal solution.

The dew point sensors Series EE355 are developed for monitoring dew point temperature down to -60 °C (-76 °F) dew point. The high measurement accuracy of ±2 °C (±3.6 °F) presents its versatility to the OEM market.

For both, integration into the measurement task is considerably simplified thanks to its highly compact design and exceptional robust stainless steel housing. The measurement values of the dew point sensor are issued on an analog 4-20 mA and a digital Modbus RTU output. Furthermore, excellent long-term stability and temperature compensation across the entire measurement range are important features of the dew point sensor series EE354.

The exact monitoring of dew point temperature in compressed air systems, dryers for plastic, and other industrial processes is becoming increasingly more important. The inline dew point meter, Series EE371, with a measuring range of -60 to 60 °C (-76 to 140 °F) is the ideal solution for such applications.
Dewpoint Transmitters with Remote Probe

The dew point monitor Series EE35 with a remote probe are based on a functional, user-friendly housing concept, and on the proven polymer humidity sensors of the HC Series. A specially developed auto-calibration process enables measurements in a measurement range of -60 to 60 °C (-76 to 140 °F) dew point temperature, with a measurement accuracy of ±2 °C (±3.6 °F). Two freely configurable and scalable analogue outputs are available for the two measurement values (Td, T). An optional hygrostat output, which can be set by means of a potentiometer, provides an alarm signal in a simple way when a threshold of the permitted dew point is exceeded. An optional display for the measurement values and the associated MIN/MAX values allows a quick overview of the current situation.

The core of the transmitter is the monolithic measurement cell type, HMC01, developed in thin-film technology. Other products developed by E+E Elektronik are air air velocity transmitters, carbon dioxide transmitters and humidity transmitters.Contact JLC International for more information or inquiries about our dewpoint transmitters by calling: 1-888-358-2518.




Shaw Dew Point Transmitter 2-wire loop powered
Model SDT

dewpoint transmitters

Specifications

  • Ranges with different engineering units:
    • -100 to +20 °C (-148 to +68 °F)
    • -65 to +20 °C (-85 to +68 °F)
    • 0.1 to 100.0 ppm(v)
    • 0.01 to 10.00 ppm(v)
    • 0.01 to 10.00 g/m3
    • 0.1 to 100.0 lbs/MMSCF
  • Accuracy: ± 2.0 °C (3.6 °F) dew point temperature
  • Output: 4 – 20 mA (2 wire loop-powered)
  • Weight: 0.385 lbs (175 g)
  • Weather proof rating NEMA 4X (IP66 )
  • Factory calibrated, traceable to international standards
  • Performance not affected by pressure or flow rate
  • Optional Stainless Steel sample cell
  • Warranty:
    • one year on calibration
    • two year mechanical




Shaw Intrinsically Safe Dew Point Transmitter
Model SDT-Ex

dew point monitor  ATEX-EX_small

Specifications

  • Ranges with different engineering units:
    • -120 to +20 °C (-184 to +68 °F)
    • -100 to +20 °C (-148 to +68 °F)
    • -65 to +20 °C (-85 to +68 °F)
    • 0.1 to 100.0 ppm(v)
    • 0.01 to 10.00 ppm(v)
    • 0.01 to 10.00 g/m3
    • 0.1 to 100.0 lbs/MMSCF
  • Accuracy: ± 2 °C (3.6 °F) dew point temperature
  • Output: 4 – 20 mA / 3-wire at 24 Vdc
  • Intrinsically Safe ATEX II I GD Ex ia IIC T4
  • Weight: 0.55 lbs (250 g)
  • Weather proof rating NEMA 4X (IP66 )
  • Factory calibrated, traceable to international standards
  • Performance not affected by pressure or flow rate
  • Optional Stainless Steel sample cell
  • Warranty:
    • one year on calibration
    • two year mechanical




Industrial Dew Point Transmitters
Series EE35







Specifications

  • Ranges Dewpoint Temperature:
    • -40 to +60 °C (-40 to +140 °F) standard
    • -60 to +60 °C (-76 to +140 °F) special
  • Process Temperature: 0 to 60 °C (32 to 140 °F
  • Accuracy: ≤ ±2 °C  (3.6 °F)
  • Auto-calibration
  • Two freely selectable and scaleable analogue outputs
  • Alarm output within -60 to 40 °C  and -60 to 40 ° F range Td
  • Pressure tight up to 20 bar (300 psi)
  • Optional graphical LC display
  • Excellent choice for dryers, compressed air lines, etc.
  • Calibrated against NIST traceable factory standards




Miniature Dewpoint Transmitter
Series EE354

EE354_small



Specifications

  • Ranges:
    • -20 to +50 °C (-4 to +122 °F) Dewpoint Temperature
    •  -40 to +60 °C (-40 to +140 °F) Process Temperature
  • Accuracy: = ±1 °C  (1.8 °F) for refrigerant dryers
  • Scaleable analogue output 4 – 20 mA (3-wire)
  • Digital interface: ModBus RTU
  • Pressure tight up to 80 bar (1160 psi)
  • Specifically designed for refrigeration dryers
  • Protection class IP65 (NEMA4X)
  • Process connection 1/2″ NPT male
  • Calibrated against NIST traceable factory standard




OEM Dew Point Transmitter
Series EE355





Specifications

  • Ranges:
    • -60 to +60 °C (-76 to +140 °F) Dew Point Temperature
    • -40 to 60 °C (-40 to +140 °F) Process Temperature
  • Accuracy: ≤ ±2 °C  (3.6 °F)
  • Scaleable analogue output 4 – 20 mA (3-wire)
  • Digital interface: ModBus RTU
  • Pressure tight up to 80 bar (1160 psi)
  • Protection class IP65 (NEMA4X)
  • Process connection 1/2″ NPT male
  • Calibrated against NIST traceable factory standard






Compact Dew Point Transmitter / Switch
Series EE371





Specifications

  • Range:
    • -60 to +60 °C (-76 to +140 °F) Dewpoint Temperature
    • -40 to +60 °C (-40 to +140 °F) Process Temperature
    • 20 to 200,000 ppm(v) moisture content
  • Accuracy: ≤ 2 °C (3.6 °F) / 5 ppm + 9% of reading
  • Outputs: 2 scaleable analogue outputs – Td, Tf or X(v) – Transmitter
    2 potential free relays – Switch
  • Auto-calibration
  • Pressure rating: 20 bar (290 psi) or 100 bar (1450 psi)
  • Optional graphical LC display
  • Excellent choice for dryers, compressed air lines, etc.
  • Calibrated against NIST traceable factory standards
